Thunderbolt 4?

TidBITS Talk
#1

For the new M1 Macs, Apple uses the term “Thunderbolt / USB 4.” I had interpreted that as meaning “Thunderbolt” (presumably 3) and “USB 4,” but I just saw an OWC article that suggests it’s really “Thunderbolt 4” and “USB 4.”

But even that article says:

As you see in the graphic below, Apple alludes to this very idea. “Thunderbolt / USB 4” is “Thunderbolt 3” – there is no need to even call it Thunderbolt 4.

A Google search on “Thunderbolt 4” +site:apple.com doesn’t provide any useful information from the horse’s mouth.

So does anyone know if we’ve really moved to Thunderbolt 4 or not?

#2

The OWC article also links to an article from July, when TB4 was introduced: Intel Introduces Thunderbolt 4: What It Is and Does It Matter?

It includes this diagram (from Intel?):

2560×1520 294 KB

In it, you can see that it pretty much says the same thing that the latest article from OWC says. It is primarily making mandatory all the features that Apple has been (optionally) supporting for several years:

  • Support for two 4K displays
  • PCIe speeds of 32 Gbit/s
  • At least one charging port (for battery-powered devices can charge on 100W or less)
  • Wake from sleep when connected to a TB dock
  • Intel VT-d based DMA protection

The new features are:

  • Universal 40 Gbit/s cables up to 2m in length
  • Support for accessories with four TB ports (that is, 4-port hubs)
  • USB4 compliant (vs. optionally compatible)

The things that have not changed from TB3 are:

  • 40 Gbit/s data rate
  • 15 W minimum power supply for downstream accessories
  • Thunderbolt networking
  • Mandatory certification and quality audits for devices and cables

In other words, the only distinguishing feature between TB4 and Apple’s existing TB3 implementation is support for 4-port hubs and USB4. Which, for all we know, they might be able to add to older TB3 Macs with a software/firmware update.

So why did Apple use the funny language instead of explicitly saying “TB4”? My guess is that the software/firmware for 4-port hubs isn’t quite finished. Until they ship that capability, they can’t legally say it’s TB4. Once they start shipping and supporting the capability, I will expect the branding to change.

2 Likes
#3

Apple’s tech specs page for the new MacBook Air specifically says Thunderbolt 3.

image1125×2436 174 KB

#4

Yes, but that list also says “USB 3.1 Gen 2” and not “USB4”. That may be a list of backward-compatibility modes, not the port’s native capabilities.

But (as I wrote above), there’s not much difference between Apple’s existing TB3 implementation and TB4.

#5

You’re right. On another tech specs page for the M1 MBA, Apple lists video support as “Thunderbolt 3 Digital Video Output”, so that’s another clue that it may be TB3, at least pending your suggested firmware update to allow TB4 dual 4K displays (Apple is only supporting one TB connected display with the M1 Macs for now, and they haven’t said/hinted that there will be a future second display supported.)

#6

Ooh. Thanks for pointing out the dual-display capability. I don’t think they can call it TB4 if they only support one Thunderbolt display, which is the case for all three M1 models (the mini only supports dual displays using one HDMI and one Thunderbolt).

If it is possible to later support two Thunderbolt displays with a firmware update, that will be great, but if the M1’s GPU can’t support it, then it won’t be until the next generation of Apple Silicon that we see the ports marketed as TB4.

In the final analysis, I think we all know what the computer supports. We’re just discussing why Apple chose to not mention a Thunderbolt version number in their marketing materials.

#7

A new OWC article is saying that Apple can’t use the Thunderbolt 4 term explicitly because the M1-based Macs don’t support 8K monitors.

And indeed, Apple seems to be sticking with the “Thunderbolt / USB 4” moniker.

#8

That page has this line:

  • You can use Thunderbolt or USB cables with Thunderbolt devices.

That I find is highly confusing to the not very technically inclined reader. If you have a cable that is certified for “USB 4”, as Apple calls it, that may well be true. However, you most certainly cannot use just any USB cable and expect a TB3 device to work with it. In fact, the very reason TB3 cables are more expensive than USB-C cables are because of their different characteristics (wires, shielding, etc.). I don’t think they’re doing people a favor when they insinuate that essentially any USB cable can be used to connect USB or TB devices. Even if we for a moment disregard that there are in fact different flavors of “USB-C cables”.

2 Likes
#9

Interesting. The chart they previously presented (see above) only says support for dual 4K displays is required. An 8K display is worse, because it has 4x as many pixels (and therefore requires 4x the bandwidth) as a single 4K display.
